SuperLive 32CH HD Analog 8MP 4K +8CH IP Hybrid DVR, Smart Human/Vehicle Motion Detection, SuperLive Plus APP, NDAA Compliant

SuperLive 32CH HD Analog 8MP 4K +8CH IP Hybrid DVR, Smart Human/Vehicle Motion Detection, SuperLive Plus APP, NDAA Compliant

SuperLive
SKU:
SPL-H8MP32-0
$1,299.00
(No reviews yet)
Condition:
New
Current Stock:
Adding to cart… The item has been added
Description

SuperLive 32CH HD Analog 8MP/4K +8CH IP Hybrid DVR, NDAA compliant

The SuperLive 32-Channel Hybrid DVR is a high‑performance professional surveillance recorder designed for commercial CCTV systems, security integrators, and enterprise‑level installations. Supporting 32 channels of 4K/8MP HD analog cameras plus 8 channels IP cameras, this hybrid DVR delivers a complete 40‑channel recording solution for large and demanding security environments.

Featuring Smart Human and Vehicle Motion Detection for 16CH Analog, Audio‑over‑Coax, and H.265/H.264 compression, the system provides accurate event detection and efficient storage management. With 8 SATA ports supporting up to 10TB per drive, it is ideal for long-term, high-resolution video archiving.

Remote monitoring is simple and secure through the SuperLive Plus App for iOS and Android, allowing users to view live video, playback events, and manage their security system from anywhere. As an NDAA Compliant DVR, this model is approved for use in government, critical infrastructure, and regulated environments.

Ideal For

  • Commercial buildings
  • Retail stores
  • NDAA-regulated sites
  • Schools and campuses
  • Large warehouse and industrial security
  • Multi‑camera surveillance systems

Features:

  • Support 32 channels HD analog (TVI/CVI/AHD/CVBS) + 8 channels IP, 40 channels in total
  • Camera resolution supported:
    • HD Analog TVI/AHD/CVI: 8MP (4K), 5MP, 4MP, 1080p, 720p
    • CVBS Standard Analog: WD1
    • IP: 8MP
  • Support 16x Audio Input, 1x Audio Output (RCA Connector)
  • Support Audio-over-Coax cable (HD-TVI format camera only)
  • Support 16CH with Smart Humans and Vehicles Motion Detection
  • Playback: 16CH simultaneously playback
  • H.265/H.264 Video compression
  • 8x SATA HDD ports up to 10TB;
  • Multi-mode recording: Manual, motion, smart event
  • Powerful mobile surveillance by smart phones with iOS and Android devices (SuperLive Plus APP)
  • NDAA Compliant

Important Installation Note

This DVR does not include built‑in PoE ports.
A PoE network switch is required to connect IP cameras (sold separately).



Specifications:



System OS Embedded Linux
Video Analog Video Input BNC x 32
BNC interface (1.0Vp-p; 75Ω)
TVI/AHD/CVI : 4K@15fps; 5MP@20fps; 4MP/3MP/1080P/720P/WD1@25fps/30fps (live)
IP Video Input 8CH (up to 16CH); Up to 8MP@30fps
Total Input 40CH
Output HDMI 1 : 4K (3840 × 2160) / 1920 × 1080 / 1280 × 1024
HDMI 2 : 1920 × 1080 / 1280 × 1024 / 1024 × 768( HDMI1 and HDMI2 output different video sources)
VGA × 1 : 1920 × 1080 / 1280 × 1024 (VGA and HDMI1 output the same video source)
BNC × 1 : CVBS ( used as the main or spot output )
Compression H.264/H.265
Multi-screen Display Main output: 1/4/6/8/9/13/16/25/32/36
AUX. output:1/4/6/8/9
Total output: 36+9
Audio Input RCA × 16
Output RCA × 1 (linear, 600Ω)
Two-way audio Take up channel one audio input
Compression G.711(U/A)
Record Resolution 4K/4K Lite / 5MP/5MP Lite/4MP/4MP Lite/3MP/1080P/1080P Lite/720P/WD1/D1
Frame Rate Analog Channel: 4K@8fps(PAL / NTSC); 4K Lite@12/15fps(PAL / NTSC); 5MP @12fps (PAL / NTSC); 5MP Lite@20fps
(PAL / NTSC); 4MP/3MP@12/15fps(PAL / NTSC); 4MP Lite/1080P /720P/WD1/D1@25fps (PAL) / 30fps (NTSC)
IP Channel: 25fps (PAL) / 30fps (NTSC)
Bit Rate 32Kbps ~ 5Mbps
Playback Playback 16CH
Search Time slice / time / event / tag /smart search
Smart Seach Highlight colors to display the camera record in a certain period of time, different colors refer to different record events
Function Play, pause, FF, FB, digital zoom, etc.
Alarm Input 16CH
Output 8CH
AI Function Smart Motion Detection Performance No
Perimeter Protection Performance No
Network Interface RJ 45 1000Mbps × 2
Protocol TCP / IP, HTTP, HTTPS, 802.1x, DHCP, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IPv6, UDP, WebSocket, PPPoE, SNMP, IGMP
Bandwidth Incoming 48Mbps (max. 96Mbps)/ 192 Mbps Outgoing Bandwidth
Client Connection Max. 20 users access
Mobile Device OS iOS, Andriod
Storage HDD SATA×8, up to 10TB per HDD
Raid RAID 0, 1, 5, 6, 10
Backup Local Backup U disk, USB mobile HDD
Network Backup Yes
Port RS485 Yes (full-duplex), connect to PTZ or keyboard
USB USB 2.0 × 2; USB 3.0 × 1
Remote Controller N/A
Others Power Supply ATX-200W
Consumption  50W ( without HDD )
Dimensions mm 445 × 436 × 90( W × D × H )
Working Environment -10~50°C, 10%~90% (humidity)
Certificate CE, FCC
Environmental Protection Comply with Directive EU RoHS, WEEE, REACH
