Camera |
|
Image Sensor |
2MP CMOS Image Sensor |
Signal System |
NTSC/ PAL |
Effective Pixels |
1920 (H) x 1080 (V) |
Minimum Illumination |
0.01 Lux @ F1.2, AGC ON, 0 Lux with IR |
Shutter time |
1/25 (1/30) s to 1/50,000 s |
Lens |
2.8 mm, Field of View: 103° |
Lens Mount |
M12 |
Day & Night |
ICR |
Angle Adjustment |
Pan: 0 - 360°, Tilt: 0 - 180°, Rotation: 0 - 360° |
Synchronization |
Internal synchronization |
Video Frame Rate |
1080p @ 25 fps / 1080p @ 30 fps |
HD Video Output |
1 Analog HD output |
S/N Ratio |
> 62dB |
General |
|
Operating Conditions |
-40°C - 60°C (-40°F - 140°F), Humidity 90% or less (non-condensing) |
Power supply |
12 VDC ± 15% |
Power Consumption |
Max. 4 W |
Protection Level |
IP66 |
IR Range |
Up to 20m |
Dimensions |
Ø70 x 154.5 mm (Ø2.76” x 6.08”) |
Weight |
400 g (0.88 lbs) |
