AC/DC Power Surge Protector up to AC40V/DC56V 2-pin terminal for power input to 2-pin terminal for power output - Pack of 2

Image 1
  • Image 1
Price:
$36.00
SKU:
SP001P
Brand:
Weight:
1.00 LBS
Shipping:
Free Shipping
Quantity:

Product Description

AC/DC Power Surge Protector  - Pack of 2 units

Model: SP001P

Features

  • 2-pin terminal for power input to 2-pin terminal for power output
  • Maximum power input AC40V(Max), DC56V(Max)
  • Protects equipment from high voltage surges from nearby lightning strikes
  • Two stage protection: 130V, AC/DC12V
  • Performs a different function than grounding requirements
  • Wide range of applications: analog CVBS CCTV system, antenna of television, satellite receivers, FM receivers, video camera, monitors, multiplexers & quad processor, VCR, etc.

SP001P installation view



Specifications

Model No. SP001P
Surge Protection Attach Time 1 ns
Maximum Surge Voltage 4 KV
Surge Life 300 surges or 100 Amps
Normal Resistance Across Coax 10,000MΩ
Surge Resistance Approx. 0Ω
Band Pass   0  ~ 1 GHZ
Power Passing Capability  130V AC/ DC, 65 Vrms at 10 Amps
Insertion Loss Less than 0.2dB
Return Loss (75 Ohms)  16dB
Power Input AC 40V (Max), DC56V(Max)
Connectors  Terminal
Dimensions  65 mm x 25 mm x 25 mm
Weight   65 g
