SuperLive 8MP 4K UHD HD Analog 4-in-1 CCTV

Outdoor IR Mini-Bullet Camera

Features

• 8.29 MP high performance CMOS
• 3840 x 2160 resolution
• 2.8 mm fixed lens
• EXIR 2.0, up to 66 ft (30 m) IR distance
• 4-in-1 video output (switchable TVI/AHD/CVI/CVBS)
• Water and dust resistant rated IP67
• Up-the-coax (UTC) Protocol

Specifications

• Image Sensor: 8.29 megapixel progressive scan CMOS
• Resolution: 3840 (H) × 2160 (V)
• Electronic Shutter: PAL: 1/12.5 s to 1/50,000 s; NTSC: 1/15 s to 1/50,000 s
• Minimum Illumination: Color: 0.01 lux @ (f/1.2, AGC on), 0 lux with IR
• Wide Dynamic Range: DWDR, 105dB
• S/N Ratio: >62 dB
• Smart IR: Support
• IR Distance: Up to 30 m IR distance
• Focal Length: 2.8 mm
• Field of view: 102.2°
• Max. Aperture: F1.2
• Pan / Tilt / Rotation: Pan: 0° to 360°; Tilt: 0° to 180°; Rotate: 0° to 360°
• Video Frame Rate
  • TVI: 8MP@12.5fps, 8MP@15fps, 5MP@20fps, 4MP@25fps, 4MP@30fps, 2MP@25fps,2MP@30fps
  • CVI: 8MP@12.5fps, 8MP@15fps
  • AHD: 5MP@20fps
  • CVBS: 960H P/N
• Day / Night: Auto/Color/BW (Black and White)
• BLC Model Support
• White Balance: ATW/ MWB
• Digital Noise Reduction: Support
• Function: Brightness, sharpness, DNR, mirror, Smart IR
• Video Output: 1 HD analog output, switchable TVI/AHD/CVI/CVBS
• Power Supply: 12 ±VDC
• Power Consumption: Max. 5.3W
• Operating Temperature: -40°C to 60°C (-40°F to 140°F), Humidity 90% or less (non-condensation)
• Storage Temperature: -40°C to 60 °C (-40°F to 140°F), Humidity 90% or less (non-condensation)
• Ingress Protection: IP67
• Dimensions: 2.28" x 2.4" x 6.42" (58 mm x 61 mm x 158.6 mm)
• Weight: Approx. 0.46 lbs (210 g)

Dimensions
