DRC-40KHD

Commax Door Camera DRC-40KHD

Commax
SKU:
DRC-40KHD
$99.00
(No reviews yet)
Weight:
2.00 LBS
Width:
10.00 (in)
Height:
4.00 (in)
Depth:
2.00 (in)
Fixed Shipping Cost:
$6.99
Current Stock:
Adding to cart… The item has been added
Description

Commax Door Camera AHD 1.3 Megapixel

Model:DRC-40KHD



DRC-40KHD



FEATURES
  • AHD 1.3Megapixel sensor
  • Compatible with AHD video doorphone monitor CDV-704MA
  • Built-in illumination sensor
  • Both indoor and outdoor use (not waterproof)
  • Surface-mounted type
  • House call and talk
  • Door release
SPECIFICATIONS
  • Power source: 12V (from monitor)
  • Wiring: 4 wires (polarity) to a monitor / 2 wires (non polarity) to a electric door lock)
  • Video Transmission Standard: NTSC
  • Image sensor: AHD 1.3MP
  • Communication: Simultaneous
  • LED: Embedded LED (activated at night)
  • Effective Viewing Angle: Horizontal 82º, Vertical 66º
  • Angle Adjustment: Up / Down 12º
  • Operating Temperature: -10ºC ~ 40ºC
  • Minimum Illumination: 0.1LUX (within300mm)
  • Distance between door camera and monitor (TIV cable): 28 meters (Ø0.5)/ 50 meters (Ø0.65) / 70 meters (Ø0.8)
  • Dimensions(mm): 96(W) x 155(H) x 32(D)
Installation Position
