Network

Network Compression

H.264 / MPEG4 / MJPEG

Multiple Video Streaming (Encode Modes,   IPS, Resolution)

4 (H.264, MPEG4, MJPEG)

LAN Port

YES

LAN Speed

10/100 Based-T Ethernet

Supported Protocols

DDNS, PPPoE, DHCP, NTP, SNTP, TCP/IP, ICMP,   SMTP, FTP, HTTP, RTP, RTSP, RTCP,IPv4, Bonjour, UPnP, DNS,UDP,IGMP, QoS

ONVIF Compatible

YES (2.0)

Frame Rate

30fps

Number of Online Users

10

Security

(1)Multiple user access levels with   password
  (2)IP address filtering
  (3)Digest authentication

Remote Access

Web browsers or CMS software

Camera

Image Sensor

1/4" SONY CMOS image sensor

CPU

8128

Video Resolution

SXGA to QQVGA

Min Illumination

1 Lux / F1.5

Shutter Speed

1/2 to 1/10,000 sec

S/N Ratio

More than 48dB (AGC off)

Lens

f3.8mm / F1.5

Viewing Angle

62.7° (Diagonal) / 53.7° (Horizontal) /   34.1° (Vertical)

White Balance

ATW

AGC

Auto

IRIS Mode

AES

POE

YES (IEEE 802.3af)

External Alarm I/O

YES (1 in / 1 out)

MicroSD Card Slot

YES

Vandal Resistance

IK08

Power Source (±10%)

12V / 1A

Operating Temperature

0℃~40℃

Current Consumption (±10%)

202.5mA

Others

Mobile Surveillance

iOS & Android mobile devices

Motion Detection

YES

Event Notification

FTP / Email / SMS

3-Axis

YES

Reset Button

YES

RTC (real-time clock)

YES

Digital Pan / Tilt / Zoom

YES

Minimum Web Browsing Requirements

- Intel core i3 or higher, or equivalent   AMD
  - 2G RAM
  - AGP graphics card, Direct Draw, 32MB RAM
  - Windows 7, Vista & XP, DirectX 9.0 or later
  - Internet Explorer 7.x or later
