HD-CVI/HD-TVI/AHD Video Converter to HDMI/VGA/Composite Video
MS
$110.00
(No reviews yet)
Write a Review
MS
HD-CVI/HD-TVI/AHD Video Converter to HDMI/VGA/Composite Video
HD CCTV HD-CVI/HD-TVI/AHD Video Converter to HDMI/VGA/Composite Video Converter
Supports display of HDMI, VGA and BNC video/HD CCTV loop out at the same time
Features:
- Converts HD CCTV (HD-CVI/ HD-TVI/ AHD) video signal to HDMI, VGA, and Composite Video.
- Supports 3 different output displays at the same time.
- Perfect solution for displaying HD-CVI/ HD-TVI/ AHD camera to a different monitor without high definition CCTV DVR.
- HDMI and DVI compliant. (Support DVI monitor by a HDMI to DVI adaptor).
- Input Support: HD-CVI/HD-TVI/AHD: 720p@25/30/50/60Hz and 1080p@25/30Hz
- Output Support: HDMI, VGA, Composite Video or HD CCTV loop out
- HDMI/VGA output support: 480p,576p,720p,1080i,1080p
- Composite video output support NTSC, PAL (CVBS)
Specifications:
|
ITEM NO |
AD001HD4 |
|
Video Input |
HD-CVI/HD-TVI/AHD: (720p@25/30/50/60Hz, 1080p@25/30Hz) |
|
Video Output |
HDMI & VGA (480p, 576p, 720p/50/60, 1080i/50/60, 1080p/50/60), Composite video (NTSC, PAL) |
|
Input Connector |
BNC (75Ω 1Vpp) |
|
Output Connector |
HDMI Type-A, D-SUB 15, BNC (75Ω 1Vpp) |
|
Switch |
Dip Switch x1, Tact Switch x 2 |
|
Power Supply |
12V 500mA |
|
Power Consumption |
350mA |
|
Temperature |
Operation: 0 to 55ºC, Storage: -20 to 85 ºC, Humidity: up to 95% |
|
Dimensions (mm) |
88 x 130 x 30 |
|
Weight (g) |
250 |
Installation View
-
-
-
-
