Hikvision 8MP 16CH NVR with 16CH POE H.265+ 4K HDMI 2 SATA DS-7616NI-Q2/16P

  • Image 1
  • Image 2
Price:
$349.00
SKU:
DS-7616NI-Q2/16P
Brand:
Weight:
10.00 LBS
Shipping:
Free Shipping

Choose Your Options

Quantity:


Product Description

Model: DS-7616NI-Q2/16P

Hikvision 8MP H.265+ 16CH NVR with 16CH PoE 2-SATA HDD (Hard Drive not included)

Features and Functions

  • H.265+/H.265/H.264/H.264+ video formats
  • Third-party network cameras supported
  • Up to 16 IP cameras can be connected
  • Supports live view, storage, and playback of the connected camera at up to 8 MP resolution
  • HDMI and VGA independent outputs
  • HDMI video output at up to 4K(3840 x 2160) resolution
  • 2 SATA interfaces connectable for recording and backup
  • H.265+ compression effectively reduces the storage space and costs by up to 75%
  • Connectable to smart IP cameras from Hikvision and the recording, playing back, and backing up of VCA alarms can be realized
  • VCA detection alarm is supported
  • Hik-Connect for easy network management
Specifications

Model

DS-7616NI-Q2/16P

Video/Audio Input

IP video input

16-ch

Two-way audio

1-ch, RCA (2.0 Vp-p, 1 k Ω

Network

Incoming Bandwidth

160 Mbps

Outgoing Bandwidth

80 Mbps

Video/Audio Output

Recording resolution

8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/

2CIF/CIF/QCIF

HDMI output

resolution

1-ch, 4K (3840 × 2160)/30Hz, 1920 × 1080p/60Hz, 1600 ×

1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz

VGA output resolution

1-ch, 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz,

1024 × 768/60Hz

Audio output

1-ch, RCA (Linear, 1 KΩ)

Decoding

Decoding format

H.265/H.265+/H.264/H.264+/MPEG4

Live view / Playback

resolution

8 MP/6 MP/5 MP/4 MP/3 MP/ 1080p/ UXGA /720p /VGA /4CIF /DCIF / 2CIF /CIF /QCIF

Synchronous playback

16-ch

Capability

1-ch @ 8 MP / 4-ch @ 1080p

Network

management

Network protocols

TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS,

iSCSI, UPnP™, HTTPS

Hard Disk

SATA

2 SATA interfaces

Capacity

Up to 6TB capacity for each disk

External Interface

Network Interface

1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface

USB interface

2 × USB 2.0

POE Interface

Interface

16, RJ-45 10/100 Mbps

self-adaptive Ethernet interface

Power

≤ 150W

Standard

IEEE 802.3 af/at

General

Power supply

100 to 240 VAC

Power

≤ 280W

Consumption

(without hard disk)

≤ 15W

Working temperature

-10°C to +55°C (+14°F to +131°F)

Working humidity

10 to 90 %

Chassis

1U chassis

Dimensions (W x D x H)

385 x 315 x 52mm (15.2” x 12.4” x 2.0”

Weight (without hard disk)

≤ 2.6 kg (5.7 lb)
