Hardware |
|
Video Inputs |
4 LAN ports |
Video Output |
1 HDMI output |
Video Output Resolution |
1920 x 1080 |
HDD Storage |
One 3TB HDD |
eSATA |
YES |
USB Ports |
Two (One for Video backup to USB flash drive, and another for NVR control via USB mouse) |
IR Remote Control |
YES |
Ethernet (LAN port 1~4) |
10/100Mbps with PON |
Ethernet (WAN port) |
1000Mbps |
Software |
|
Video Compression Format |
H.264 |
Local / Remote Display Mode |
4CH |
Local / Remote Playback Mode |
4CH |
Recording Mode |
Manual / Event / Alarm / Schedule |
Recording Throughput |
Up to 120 IPS @ 1280 x 1024, 32Mbps |
Pre-alarm Recording |
YES |
Quick Search |
Time / Event |
Security |
Multiple user access levels with password |
Remote Access |
(1) Internet Explorer on Windows operating system |
General |
|
Power Source (±10%) |
DC48V / 1.25A |
Camera power supply over PON |
YES |
Operating Temperature |
10℃ ~ 40℃ (50℉ ~ 104℉) |
Minimum PC Browsing Requirement |
- Intel core i3 CPU or higher or equivalent AMD processor |
