Camera

Image Sensor

2MP CMOS Image Sensor

Signal System

NTSC/ PAL

Effective Pixels

1920 (H) x 1080 (V)

Minimum Illumination

0.1 Lux @ F1.2, AGC ON, 0 Lux with IR

Shutter time

1/25 (1/30) s to 1/50,000 s

Lens

2.8 mm, Field of View:  103°

Lens Mount

M12

Day & Night

ICR

Angle Adjustment

Pan: 0 - 360°, Tilt: 0 - 75°, Rotation: 0 - 360°

Synchronization

Internal synchronization

Video Frame Rate

1080p @ 25 fps / 1080p @ 30 fps

HD Video Output

1 Analog HD output

S/N Ratio

> 62dB

General

Operating Conditions

-40°C - 60°C (-40°F - 140°F), Humidity 90% or less (non-condensing)

Power supply

12 VDC ± 15%

Power Consumption

Max. 4 W

Protection Level

IP66

IR Range

Up to 20m

Dimensions

Ø89.47 x 67.6 mm (Ø3.52” x 2.7”)

Weight

340 g (0.75 lbs)
