750 TVL WDR Box Camera

750tvl wdr box camera
  • 750tvl wdr box camera
  • 750tvl wdr box camera
Price:
$85.00
Weight:
2.00 LBS
Shipping:
Free Shipping
Quantity:

Product Description

BX-750-WDR-EV

  • WDR Box Camera
  • 1/3" SONY Super HAD II CCD (960H)
  • 750TVL
  • C/CS Mount lens
Model BX-750-WDR-EV
Pick up device 1/3" SONY Super HAD II CCD (960H)
Total Pixels
  • NTSC 976(H) × 494(V)
  • PAL 976(H) × 582(V)
Sensing Area 4.9mm × 3.7mm
Scanning System Interlaced
Sync. System Internal
Resolution 750 TVL
Lens Mount lens C/CS
O.S.D Built-in
AGC Auto, Manual, OFF
White Balance ATW, PUSH, PUSH LOCK, USER1, USER2, MANUAL
BLC On / Off
DNR 3DNR
Image Adjustment Brightness, Contrast, Sharpness, Hue, Color Gain
Motion Detection Off / On (4 areas)
Privacy Zones Off / On (15 areas)
Defog Off / On
Day & Night Auto, Day, Night
WDR 128 dB, Super Wide Dynamic Range, ATR-EX
System Setting Sync mode, less, flip, LCD / CRT, Camera ID
S/N Ratio More than 52dB (AGC OFF)
Electronic Shutter (1/60 (1/50) ~ 1/100,000s)
Video Output 1.0 Vp-p Composite Video, 75Ω
Minimum Illumination
  • Color: 0.03Lux/F1.2
  • B/W: 0.00009Lux/F1.2 (sens-up on)
Power Source DC12V±10%
Current Consumption 200 mA
Operation Temperature  -10ºC ~ 55ºC
Dimension 81 × 72 × 148 mm
Weight 485 g
