CAMERA |
|
Sensor | 1/3" SONY EX-view HADⅡCCD 960H |
Effective pixels | NTSC:976x494,PAL:976x582 |
Resolution
|
700TVL |
Min. illumination | 0Lux (IR ON) |
Scan System | 2:1 interlace |
Sycn System | Internal |
Lens | 2.8-11mm Manual/DC/ICR Lens |
Electronic shutter | Auto(1/60(1/50)~1/100,000) /Fixed/ Manual |
S/N Rate
|
52 dB(AGC OFF) |
Video Output | 1.0Vp-p composite video output, 75Ώ |
OSD MENU |
|
White Balance | ATW/MANUAL/ONE PUSH/ FIXED/ CRR/ USER1/USER2 |
NR | 3D Noise reduction |
Image Adjustable | Lightness/Contrast/Sharpness |
DWDR | NORMAL/LIGHT/FULL |
BLC
|
BLC/HLC/OFF |
AGC | ON/ OFF |
Day/Night | Auto/Color/B/W/EXT |
Privacy Zones | ON/OFF(15 zones) |
Motion Detection | ON/OFF(4 zones) |
Mirror | OFF/V-FLIP/H-PLIP/HV-FLIP |
Gamma
|
0.45/ USER(0.05-1.0 adjustable) |
OSD Menu | English |
GENERAL
|
|
IR distance | 10-15 m(18xΦ5) |
Power Supply | DC12V± 10% |
Power Consumption | 300mA/DC12V |
Operating Conditions
|
'-10°C ~ 55°C/ 0%-90% |
Dimensions | 112(H)*150(D)mm |
Weight/PCS
|
About 855g |
